    The ADZ series low-temperature full-combustion engine is primarily developed for drying equipment with high flue gas volume at low temperatures. It can operate stably under conditions of high negative pressure and zero-pressure furnace chambers, where the flue gas is dense and hot. Suitable for combustion scenarios near atmospheric pressure, such as textile machinery, printing machines, and other types of dryers in the textile industry. This product features dual electromagnetic valve safety protection, air pressure monitoring, and a burner controller with purge function, paired with ion rods for flame detection, ensuring stable and reliable performance. Different control components, burners, and system displays can be selected according to customer requirements.

    • ￥0.00
      ￥0.00
      ￥0.00
      ￥0.00

    • Satisfaction：

      Sales： 0

      Review： 0

    Weight：0.000KG
    • Quantity：
Description

The ADZ series low-temperature full-combustion engine is primarily developed for drying equipment with high flue gas volume at low temperatures. It can operate stably under conditions of high negative pressure and zero-pressure furnace chambers, where the flue gas is dense and hot. Suitable for combustion scenarios near atmospheric pressure, such as textile machinery, printing machines, and other types of dryers in the textile industry. This product features dual electromagnetic valve safety protection, air pressure monitoring, and a burner controller with purge function, paired with ion rods for flame detection, ensuring stable and reliable performance. Different control components, burners, and system displays can be selected according to customer requirements.

Product Parameter
Product model:Burner 1Burner 2
Maximum power: 230KW (200,000 kcal)350KW

Minimum power:

5KW

10KW

Ratio of adjustment:

1:35

1 :35

Adjustment mode:

Mechanical proportional adjustment

Set the air volume to adjust the gas

Load regulation mode:

Three-line motor valve position control

Three-line motor reading control

Detection method:

Ion detection

UV check

Fuel type:

Natural gas or liquefied petroleum gas

Water gas

Maximum gas flow:

23NM³

140NM³

Minimum gas flow rate:

0.5NM³

4NM³

Gas inlet pressure of burner:

50mbar

50mbar

Gas inlet direction:

 Left inlet

Intermediate intake

Blower motor power: Single phase 220V 50Hz 400W

Three-phase 380V 50Hz 750W

Weight: 65Kg

90Kg

Flame length: 650mm500mm
